What is 6082 Aluminum Alloy

In plate form, 6082 is the alloy most commonly used for general machining. It is widely used in Europe and has replaced 6061 alloy in many applications, primarily due to its higher strength (from a large amount of manganese) and its excellent resistance to corrosion. It is typically seen in transport, scaffolding, bridges and general engineering.

Chemical Composition WT(%)

Silicon

Iron

Copper

Magnesium

Manganese

Chromium

Zinc

Titanium

Others

Aluminum

0.7~1.3

0.5

0.1

0.6~1.2

0.4~1.0

0.25

0.2

0.1

0.15

Balance

Temper Types

Most common tempers for 6082 alloy are:

F - As fabricated.
T5 - Cooled from an elevated temperature shaping process and artificially aged. Applies to products that are not cold worked after cooling.
T5511 - Cooled from an elevated temperature shaping process, stress relieved by stretching and artificially aged.
T6 - Solution heat treated and artificially aged.
O - Annealed. This is the lowest strength, highest ductility temper.
T4 - Solution heat treated and naturally aged to a substantially stable condition. Applies to products that are not cold worked after solution heat-treatment.
T6511 - Solution heat treated, stress relieved by stretching, and artificially aged.

Typical Mechanical Properties

Temper

Thickness

(mm)

Tensile Strength

(Mpa)

Yield Strength

(Mpa)

Elongation

(%)

T4 0.4~1.50

≥205

≥110

≥12

T4 >1.50~3.00

≥14

T4 >3.00~6.00

≥15

T4 >6.00~12.50

≥14

T4 >12.50~40.00

≥13

T4 >40.00~80.00

≥12

T6 0.4~1.50

≥310

≥260

≥6

T6 >1.50~3.00

≥7

T6 >3.00~6.00

≥10

T6 >6.00~12.50 ≥300 ≥255 ≥9

Alloy 6082 Properties

Alloy 6082 offers similar, but not equivalent, physical characteristics to 6061 alloy, and slightly higher mechanical properties in the -T6 condition. It has good finishing characteristics and responds well to the most common anodic coatings (i.e., clear, clear and dye, hardcoat).

Various commercial joining methods (e.g., welding, brazing, etc.) can be applied to alloy 6082; however, heat treatment may reduce strength in the weld region. It provides good machinability in the –T5 and –T6 tempers, but chip breakers or special machining techniques (e.g., peck drilling) are recommended for improving chip formation.

The -0 or -T4 temper is recommended when bending or forming alloy 6082. It can also be difficult to produce thin walled extrusion shapes in 6082 alloy, so -T6 temper may not be available due to alloy quenching limitations.

Uses for 6082 Alloy

Alloy 6082’s good weldability, brazeability, corrosion resistance, formability and machinability make it useful for rod, bar and machining stock, seamless aluminum tubing, structural profiles and custom profiles.

These characteristics, as well as its light weight and excellent mechanical properties, contributed to the use of 6082-T6 alloy in automobile, aviation and high-speed rail applications.
